cleanup repository
This commit is contained in:
Maik Hofmann
parent
32026a4096
commit
8c2b3500d6
5
HCPBridge/.gitignore
vendored
5
HCPBridge/.gitignore
vendored
@ -1,5 +0,0 @@
|
|||||||
/.pio
|
|
||||||
.vscode/.browse.c_cpp.db*
|
|
||||||
.vscode/c_cpp_properties.json
|
|
||||||
.vscode/launch.json
|
|
||||||
.vscode/ipch
|
|
||||||
@ -1,39 +0,0 @@
|
|||||||
|
|
||||||
This directory is intended for project header files.
|
|
||||||
|
|
||||||
A header file is a file containing C declarations and macro definitions
|
|
||||||
to be shared between several project source files. You request the use of a
|
|
||||||
header file in your project source file (C, C++, etc) located in `src` folder
|
|
||||||
by including it, with the C preprocessing directive `#include'.
|
|
||||||
|
|
||||||
```src/main.c
|
|
||||||
|
|
||||||
#include "header.h"
|
|
||||||
|
|
||||||
int main (void)
|
|
||||||
{
|
|
||||||
...
|
|
||||||
}
|
|
||||||
```
|
|
||||||
|
|
||||||
Including a header file produces the same results as copying the header file
|
|
||||||
into each source file that needs it. Such copying would be time-consuming
|
|
||||||
and error-prone. With a header file, the related declarations appear
|
|
||||||
in only one place. If they need to be changed, they can be changed in one
|
|
||||||
place, and programs that include the header file will automatically use the
|
|
||||||
new version when next recompiled. The header file eliminates the labor of
|
|
||||||
finding and changing all the copies as well as the risk that a failure to
|
|
||||||
find one copy will result in inconsistencies within a program.
|
|
||||||
|
|
||||||
In C, the usual convention is to give header files names that end with `.h'.
|
|
||||||
It is most portable to use only letters, digits, dashes, and underscores in
|
|
||||||
header file names, and at most one dot.
|
|
||||||
|
|
||||||
Read more about using header files in official GCC documentation:
|
|
||||||
|
|
||||||
* Include Syntax
|
|
||||||
* Include Operation
|
|
||||||
* Once-Only Headers
|
|
||||||
* Computed Includes
|
|
||||||
|
|
||||||
https://gcc.gnu.org/onlinedocs/cpp/Header-Files.html
|
|
||||||
@ -1,46 +0,0 @@
|
|||||||
|
|
||||||
This directory is intended for project specific (private) libraries.
|
|
||||||
PlatformIO will compile them to static libraries and link into executable file.
|
|
||||||
|
|
||||||
The source code of each library should be placed in a an own separate directory
|
|
||||||
("lib/your_library_name/[here are source files]").
|
|
||||||
|
|
||||||
For example, see a structure of the following two libraries `Foo` and `Bar`:
|
|
||||||
|
|
||||||
|--lib
|
|
||||||
| |
|
|
||||||
| |--Bar
|
|
||||||
| | |--docs
|
|
||||||
| | |--examples
|
|
||||||
| | |--src
|
|
||||||
| | |- Bar.c
|
|
||||||
| | |- Bar.h
|
|
||||||
| | |- library.json (optional, custom build options, etc) https://docs.platformio.org/page/librarymanager/config.html
|
|
||||||
| |
|
|
||||||
| |--Foo
|
|
||||||
| | |- Foo.c
|
|
||||||
| | |- Foo.h
|
|
||||||
| |
|
|
||||||
| |- README --> THIS FILE
|
|
||||||
|
|
|
||||||
|- platformio.ini
|
|
||||||
|--src
|
|
||||||
|- main.c
|
|
||||||
|
|
||||||
and a contents of `src/main.c`:
|
|
||||||
```
|
|
||||||
#include <Foo.h>
|
|
||||||
#include <Bar.h>
|
|
||||||
|
|
||||||
int main (void)
|
|
||||||
{
|
|
||||||
...
|
|
||||||
}
|
|
||||||
|
|
||||||
```
|
|
||||||
|
|
||||||
PlatformIO Library Dependency Finder will find automatically dependent
|
|
||||||
libraries scanning project source files.
|
|
||||||
|
|
||||||
More information about PlatformIO Library Dependency Finder
|
|
||||||
- https://docs.platformio.org/page/librarymanager/ldf.html
|
|
||||||
@ -1,17 +0,0 @@
|
|||||||
; PlatformIO Project Configuration File
|
|
||||||
;
|
|
||||||
; Build options: build flags, source filter
|
|
||||||
; Upload options: custom upload port, speed and extra flags
|
|
||||||
; Library options: dependencies, extra library storages
|
|
||||||
; Advanced options: extra scripting
|
|
||||||
;
|
|
||||||
; Please visit documentation for the other options and examples
|
|
||||||
; https://docs.platformio.org/page/projectconf.html
|
|
||||||
|
|
||||||
[env:esp12e]
|
|
||||||
platform = espressif8266
|
|
||||||
board = esp12e
|
|
||||||
framework = arduino
|
|
||||||
lib_deps =
|
|
||||||
ottowinter/ESPAsyncWebServer-esphome@^1.2.7
|
|
||||||
bblanchon/ArduinoJson@^6.17.2
|
|
||||||
@ -1,425 +0,0 @@
|
|||||||
#include "hciemulator.h"
|
|
||||||
#define CHECKCHANGEDSET(Target,Value,Flag) if((Target)!=(Value)){Target=Value;Flag=true;}
|
|
||||||
int hciloglevel = DEFAULTLOGLEVEL;
|
|
||||||
|
|
||||||
#ifdef SOFTSERIAL
|
|
||||||
#define Log(Level,Message) LogCore(Level,Message)
|
|
||||||
#define Log3(Level,Message,Buffer, Len) LogCore(Level,Message,Buffer,Len)
|
|
||||||
//LOGLEVEL
|
|
||||||
void LogCore(int Level, const char* msg, const unsigned char * data=NULL, size_t datalen=0){
|
|
||||||
if(Level>hciloglevel){
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
if(data!=NULL && datalen>0){
|
|
||||||
String newmsg(msg);
|
|
||||||
char str[4];
|
|
||||||
for (size_t i = 0; i < datalen; i++){
|
|
||||||
snprintf(str,sizeof(str),"%02x ", data[i]);
|
|
||||||
newmsg+=str;
|
|
||||||
}
|
|
||||||
Serial.println(newmsg);
|
|
||||||
}else{
|
|
||||||
Serial.println(msg);
|
|
||||||
}
|
|
||||||
}
|
|
||||||
#else
|
|
||||||
#define Log(Level,Message)
|
|
||||||
#define Log3(Level,Message,Buffer, Len)
|
|
||||||
#endif
|
|
||||||
|
|
||||||
|
|
||||||
int HCIEmulator::getLogLevel(){
|
|
||||||
return hciloglevel;
|
|
||||||
|
|
||||||
}
|
|
||||||
void HCIEmulator::setLogLevel(int level){
|
|
||||||
hciloglevel=level;
|
|
||||||
}
|
|
||||||
|
|
||||||
//modbus crc calculation borrowed from:
|
|
||||||
//https://github.com/yaacov/ArduinoModbusSlave
|
|
||||||
#define MODBUS_CRC_LENGTH 2
|
|
||||||
#define readCRC(arr, length) word(arr[(length - MODBUS_CRC_LENGTH) + 1], arr[length - MODBUS_CRC_LENGTH])
|
|
||||||
#define readUInt16(arr, index) word(arr[index], arr[index + 1])
|
|
||||||
/**
|
|
||||||
* Calculate the CRC of the passed byte array from zero up to the passed length.
|
|
||||||
*
|
|
||||||
* @param buffer The byte array containing the data.
|
|
||||||
* @param length The length of the byte array.
|
|
||||||
*
|
|
||||||
* @return The calculated CRC as an unsigned 16 bit integer.
|
|
||||||
*
|
|
||||||
* Calculate and add the CRC.
|
|
||||||
* uint16_t crc = Modbus::calculateCRC(_responseBuffer, _responseBufferLength - MODBUS_CRC_LENGTH);
|
|
||||||
* _responseBuffer[_responseBufferLength - MODBUS_CRC_LENGTH] = crc & 0xFF;
|
|
||||||
* _responseBuffer[(_responseBufferLength - MODBUS_CRC_LENGTH) + 1] = crc >> 8;
|
|
||||||
*
|
|
||||||
*
|
|
||||||
* #define MODBUS_FRAME_SIZE 4
|
|
||||||
* #define MODBUS_CRC_LENGTH 2
|
|
||||||
* uint16_t crc = readCRC(_requestBuffer, _requestBufferLength);
|
|
||||||
* #define readUInt16(arr, index) word(arr[index], arr[index + 1])
|
|
||||||
* #define readCRC(arr, length) word(arr[(length - MODBUS_CRC_LENGTH) + 1], arr[length - MODBUS_CRC_LENGTH])
|
|
||||||
*/
|
|
||||||
uint16_t calculateCRC(uint8_t *buffer, int length)
|
|
||||||
{
|
|
||||||
int i, j;
|
|
||||||
uint16_t crc = 0xFFFF;
|
|
||||||
uint16_t tmp;
|
|
||||||
|
|
||||||
// Calculate the CRC.
|
|
||||||
for (i = 0; i < length; i++)
|
|
||||||
{
|
|
||||||
crc = crc ^ buffer[i];
|
|
||||||
for (j = 0; j < 8; j++)
|
|
||||||
{
|
|
||||||
tmp = crc & 0x0001;
|
|
||||||
crc = crc >> 1;
|
|
||||||
if (tmp)
|
|
||||||
{
|
|
||||||
crc = crc ^ 0xA001;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
}
|
|
||||||
return crc;
|
|
||||||
}
|
|
||||||
|
|
||||||
HCIEmulator::HCIEmulator(Stream * port) {
|
|
||||||
m_state.valid = false;
|
|
||||||
m_statemachine=WAITING;
|
|
||||||
m_rxlen = m_txlen = 0;
|
|
||||||
m_recvTime=m_lastStateTime=0;
|
|
||||||
m_skipFrame=false;
|
|
||||||
m_port = port;
|
|
||||||
m_statusCallback = NULL;
|
|
||||||
setLogLevel(DEFAULTLOGLEVEL);
|
|
||||||
};
|
|
||||||
|
|
||||||
void HCIEmulator::poll(){
|
|
||||||
|
|
||||||
if(m_port==NULL) return;
|
|
||||||
|
|
||||||
// receive Data
|
|
||||||
if(m_port->available() >0)
|
|
||||||
{
|
|
||||||
m_rxlen+= m_port->readBytes((char*)(m_rxbuffer+m_rxlen), _min((int)(255-m_rxlen),m_port->available()));
|
|
||||||
if(m_rxlen > 254)
|
|
||||||
{
|
|
||||||
Log(LL_ERROR,"RX Bufferoverflow, skip next Frame");
|
|
||||||
Log3(LL_DEBUG,"Buffer Data: ", m_rxbuffer, m_rxlen);
|
|
||||||
m_rxlen=0;
|
|
||||||
m_skipFrame = true;
|
|
||||||
}
|
|
||||||
m_recvTime = micros();
|
|
||||||
}
|
|
||||||
|
|
||||||
|
|
||||||
// check frame, process frame
|
|
||||||
if(m_rxlen>0 && (micros()-m_recvTime > T3_5))
|
|
||||||
{
|
|
||||||
// check last action timeout -> reset > then 2sec
|
|
||||||
if(m_statemachine!= WAITING && m_lastStateTime+2000<millis()){
|
|
||||||
m_statemachine = WAITING;
|
|
||||||
}
|
|
||||||
|
|
||||||
if(!m_skipFrame){
|
|
||||||
|
|
||||||
processFrame();
|
|
||||||
|
|
||||||
// send response
|
|
||||||
if(m_txlen > 0){
|
|
||||||
|
|
||||||
// fix crc
|
|
||||||
uint16_t crc = calculateCRC(m_txbuffer, m_txlen - MODBUS_CRC_LENGTH);
|
|
||||||
m_txbuffer[m_txlen - MODBUS_CRC_LENGTH] = crc & 0xFF;
|
|
||||||
m_txbuffer[(m_txlen - MODBUS_CRC_LENGTH) + 1] = crc >> 8;
|
|
||||||
|
|
||||||
// send data
|
|
||||||
m_lastSendTime = micros()-m_recvTime;
|
|
||||||
|
|
||||||
//Log(LL_DEBUG, ("ST:"+String(m_lastSendTime)).c_str());
|
|
||||||
|
|
||||||
m_port->write(m_txbuffer, m_txlen);
|
|
||||||
Log3(LL_DEBUG,"Response: ", m_txbuffer, m_txlen);
|
|
||||||
m_txlen = 0;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
m_skipFrame = false;
|
|
||||||
m_rxlen=0;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::processFrame(){
|
|
||||||
m_txlen = 0; // clear send buffer
|
|
||||||
|
|
||||||
if(m_rxlen<5) {
|
|
||||||
Log(LL_ERROR,"Frame skipped, invalid frame len");
|
|
||||||
Log3(LL_ERROR,"Data:", m_rxbuffer,m_rxlen);
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
|
|
||||||
// check device id, pass only device id 2 and 0 (broadcast)
|
|
||||||
if(m_rxbuffer[0] != BROADCASTID && m_rxbuffer[0] != DEVICEID){
|
|
||||||
Log(LL_DEBUG,"Frame skipped, unsupported device id");
|
|
||||||
Log3(LL_DEBUG,"Data:", m_rxbuffer,m_rxlen);
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
|
|
||||||
// check crc
|
|
||||||
uint16_t crc = readCRC(m_rxbuffer, m_rxlen);
|
|
||||||
if(crc != calculateCRC(m_rxbuffer,m_rxlen-MODBUS_CRC_LENGTH)){
|
|
||||||
Log3(LL_ERROR,"Frame skipped, wrong crc", m_rxbuffer,m_rxlen);
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
|
|
||||||
Log3(LL_DEBUG,"Incomming Data: ", m_rxbuffer, m_rxlen);
|
|
||||||
|
|
||||||
// dispatch modbus function
|
|
||||||
switch(m_rxbuffer[1]){
|
|
||||||
case 0x10:{ // Write Multiple registers
|
|
||||||
if(m_rxlen == 0x1b && m_rxbuffer[0] == BROADCASTID)
|
|
||||||
{
|
|
||||||
processBroadcastStatusFrame();
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
break;
|
|
||||||
}
|
|
||||||
|
|
||||||
case 0x17:{ // Read/Write Multiple registers
|
|
||||||
if(m_rxbuffer[0] == DEVICEID){
|
|
||||||
switch(m_rxlen){
|
|
||||||
case 0x11:{
|
|
||||||
processDeviceStatusFrame();
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
|
|
||||||
case 0x13:
|
|
||||||
processDeviceBusScanFrame();
|
|
||||||
return;;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
break;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
Log3(LL_ERROR,"Frame skipped, unexpected data: ", m_rxbuffer, m_rxlen);
|
|
||||||
}
|
|
||||||
|
|
||||||
const unsigned char ResponseTemplate_Fcn17_Cmd03_L08 []= {0x02,0x17,0x10,0x3E,0x00,0x03,0x01,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x74,0x1B};
|
|
||||||
const unsigned char ResponseTemplate_Fcn17_Cmd04_L02 []= {0x02,0x17,0x04,0x0F,0x00,0x04,0xFD,0x0A,0x72};
|
|
||||||
void HCIEmulator::processDeviceStatusFrame(){
|
|
||||||
if(m_rxlen==0x11){
|
|
||||||
unsigned char counter = m_rxbuffer[11];
|
|
||||||
unsigned char cmd = m_rxbuffer[12];
|
|
||||||
if(m_rxbuffer[5] == 0x08){
|
|
||||||
// expose internal state
|
|
||||||
// 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
|
|
||||||
//0011: 02 17 9C B9 00 08 9C 41 00 02 04 3E 03 00 00 EB CC
|
|
||||||
//res=> 02 17 10 3E 00 03 01 00 00 00 00 00 00 00 00 00 00 00 00 74 1B
|
|
||||||
memcpy_P(m_txbuffer, ResponseTemplate_Fcn17_Cmd03_L08, sizeof(ResponseTemplate_Fcn17_Cmd03_L08));
|
|
||||||
m_txbuffer[0] = m_rxbuffer[0];
|
|
||||||
m_txbuffer[3] = counter;
|
|
||||||
m_txbuffer[5] = cmd;
|
|
||||||
m_txlen = sizeof(ResponseTemplate_Fcn17_Cmd03_L08);
|
|
||||||
|
|
||||||
|
|
||||||
switch(m_statemachine)
|
|
||||||
{
|
|
||||||
// open Door
|
|
||||||
case STARTOPENDOOR:
|
|
||||||
m_txbuffer[7]= 0x02;
|
|
||||||
m_txbuffer[8]= 0x10;
|
|
||||||
m_statemachine = STARTOPENDOOR_RELEASE;
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
break;
|
|
||||||
case STARTOPENDOOR_RELEASE:
|
|
||||||
if(m_lastStateTime+SIMULATEKEYPRESSDELAYMS<millis()){
|
|
||||||
m_txbuffer[7]= 0x01;
|
|
||||||
m_txbuffer[8]= 0x10;
|
|
||||||
m_statemachine = WAITING;
|
|
||||||
}
|
|
||||||
break;
|
|
||||||
|
|
||||||
// close Door
|
|
||||||
case STARTCLOSEDOOR:
|
|
||||||
m_txbuffer[7]= 0x02;
|
|
||||||
m_txbuffer[8]= 0x20;
|
|
||||||
m_statemachine = STARTCLOSEDOOR_RELEASE;
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
break;
|
|
||||||
case STARTCLOSEDOOR_RELEASE:
|
|
||||||
if(m_lastStateTime+SIMULATEKEYPRESSDELAYMS<millis()){
|
|
||||||
m_txbuffer[7]= 0x01;
|
|
||||||
m_txbuffer[8]= 0x20;
|
|
||||||
m_statemachine = WAITING;
|
|
||||||
}
|
|
||||||
break;
|
|
||||||
|
|
||||||
// stop Door
|
|
||||||
case STARTSTOPDOOR:
|
|
||||||
m_txbuffer[7]= 0x02;
|
|
||||||
m_txbuffer[8]= 0x40;
|
|
||||||
m_statemachine = STARTSTOPDOOR_RELEASE;
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
break;
|
|
||||||
case STARTSTOPDOOR_RELEASE:
|
|
||||||
if(m_lastStateTime+SIMULATEKEYPRESSDELAYMS<millis()){
|
|
||||||
m_txbuffer[7]= 0x01;
|
|
||||||
m_txbuffer[8]= 0x40;
|
|
||||||
m_statemachine = WAITING;
|
|
||||||
}
|
|
||||||
break;
|
|
||||||
|
|
||||||
// Ventilation
|
|
||||||
case STARTVENTPOSITION:
|
|
||||||
m_txbuffer[7]= 0x02;
|
|
||||||
m_txbuffer[9]= 0x40;
|
|
||||||
m_statemachine = STARTVENTPOSITION_RELEASE;
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
break;
|
|
||||||
case STARTVENTPOSITION_RELEASE:
|
|
||||||
if(m_lastStateTime+SIMULATEKEYPRESSDELAYMS<millis()){
|
|
||||||
m_txbuffer[7]= 0x01;
|
|
||||||
m_txbuffer[9]= 0x40;
|
|
||||||
m_statemachine = WAITING;
|
|
||||||
}
|
|
||||||
break;
|
|
||||||
|
|
||||||
|
|
||||||
// Half Position
|
|
||||||
case STARTOPENDOORHALF:
|
|
||||||
m_txbuffer[7]= 0x02;
|
|
||||||
m_txbuffer[9]= 0x04;
|
|
||||||
m_statemachine = STARTOPENDOORHALF_RELEASE;
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
break;
|
|
||||||
|
|
||||||
case STARTOPENDOORHALF_RELEASE:
|
|
||||||
if(m_lastStateTime+SIMULATEKEYPRESSDELAYMS<millis()){
|
|
||||||
m_txbuffer[7]= 0x01;
|
|
||||||
m_txbuffer[9]= 0x04;
|
|
||||||
m_statemachine = WAITING;
|
|
||||||
}
|
|
||||||
break;
|
|
||||||
|
|
||||||
// Toggle Lamp
|
|
||||||
case STARTTOGGLELAMP:
|
|
||||||
m_txbuffer[7]= 0x10;
|
|
||||||
m_txbuffer[9]= 0x02;
|
|
||||||
m_statemachine = STARTTOGGLELAMP_RELEASE;
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
break;
|
|
||||||
case STARTTOGGLELAMP_RELEASE:
|
|
||||||
if(m_lastStateTime+SIMULATEKEYPRESSDELAYMS<millis()){
|
|
||||||
m_txbuffer[7]= 0x08;
|
|
||||||
m_txbuffer[9]= 0x02;
|
|
||||||
m_statemachine = WAITING;
|
|
||||||
}
|
|
||||||
break;
|
|
||||||
|
|
||||||
case WAITING:
|
|
||||||
break;
|
|
||||||
}
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
else if(m_rxbuffer[5] == 0x02){
|
|
||||||
// 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
|
|
||||||
//0011: 02 17 9C B9 00 02 9C 41 00 02 04 0F 04 17 00 7B 21
|
|
||||||
//res=> 02 17 04 0F 00 04 FD 0A 72
|
|
||||||
memcpy_P(m_txbuffer, ResponseTemplate_Fcn17_Cmd04_L02, sizeof(ResponseTemplate_Fcn17_Cmd04_L02));
|
|
||||||
m_txbuffer[0] = m_rxbuffer[0];
|
|
||||||
m_txbuffer[3] = counter;
|
|
||||||
m_txbuffer[5] = cmd;
|
|
||||||
m_txlen = sizeof(ResponseTemplate_Fcn17_Cmd04_L02);
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
Log3(LL_ERROR,"Frame skipped, unexpected data: ", m_rxbuffer, m_rxlen);
|
|
||||||
}
|
|
||||||
|
|
||||||
const unsigned char ResponseTemplate_Fcn17_Cmd02_L05 []= {0x02,0x17,0x0a,0x00,0x00,0x02,0x05,0x04,0x30,0x10,0xff,0xa8,0x45,0x0e,0xdf};
|
|
||||||
void HCIEmulator::processDeviceBusScanFrame(){
|
|
||||||
// 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
|
|
||||||
//0013: 02 17 9C B9 00 05 9C 41 00 03 06 00 02 00 00 01 02 f8 35
|
|
||||||
//res=> 02 17 0a 00 00 02 05 04 30 10 ff a8 45 0e df
|
|
||||||
unsigned char counter = m_rxbuffer[11];
|
|
||||||
unsigned char cmd = m_rxbuffer[12];
|
|
||||||
memcpy_P(m_txbuffer, ResponseTemplate_Fcn17_Cmd02_L05, sizeof(ResponseTemplate_Fcn17_Cmd02_L05));
|
|
||||||
m_txbuffer[0] = m_rxbuffer[0];
|
|
||||||
m_txbuffer[3] = counter;
|
|
||||||
m_txbuffer[5] = cmd;
|
|
||||||
m_txlen = sizeof(ResponseTemplate_Fcn17_Cmd02_L05);
|
|
||||||
|
|
||||||
Log(LL_INFO,"Busscan received");
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::processBroadcastStatusFrame(){
|
|
||||||
//001B: 00 10 9D 31 00 09 12 64 00 00 00 40 60 00 00 00 00 00 00 00 00 00 01 00 00 CA 22
|
|
||||||
bool hasChanged = false;
|
|
||||||
CHECKCHANGEDSET(m_state.lampOn,m_rxbuffer[20] == 0x14,hasChanged);
|
|
||||||
CHECKCHANGEDSET(m_state.doorCurrentPosition,m_rxbuffer[10],hasChanged);
|
|
||||||
CHECKCHANGEDSET(m_state.doorTargetPosition, m_rxbuffer[9],hasChanged);
|
|
||||||
CHECKCHANGEDSET(m_state.doorState, m_rxbuffer[11],hasChanged);
|
|
||||||
CHECKCHANGEDSET(m_state.reserved, m_rxbuffer[17],hasChanged);
|
|
||||||
CHECKCHANGEDSET(m_state.valid, true,hasChanged);
|
|
||||||
|
|
||||||
if(hasChanged){
|
|
||||||
Log3(LL_INFO,"New State: ",m_rxbuffer,m_rxlen);
|
|
||||||
if(m_statusCallback != NULL){
|
|
||||||
m_statusCallback(m_state);
|
|
||||||
}
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::openDoor(){
|
|
||||||
if(m_statemachine != WAITING){
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
m_statemachine = STARTOPENDOOR;
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::openDoorHalf(){
|
|
||||||
if(m_statemachine != WAITING){
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
m_statemachine = STARTOPENDOORHALF;
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::closeDoor(){
|
|
||||||
if(m_statemachine != WAITING){
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
m_statemachine = STARTCLOSEDOOR;
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::stopDoor(){
|
|
||||||
if(m_statemachine != WAITING){
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
m_statemachine = STARTSTOPDOOR;
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::toggleLamp(){
|
|
||||||
if(m_statemachine != WAITING){
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
m_statemachine = STARTTOGGLELAMP;
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::ventilationPosition(){
|
|
||||||
if(m_statemachine != WAITING){
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
m_lastStateTime = millis();
|
|
||||||
m_statemachine = STARTVENTPOSITION;
|
|
||||||
}
|
|
||||||
|
|
||||||
void HCIEmulator::onStatusChanged(callback_function_t handler) {
|
|
||||||
m_statusCallback = handler;
|
|
||||||
}
|
|
||||||
@ -1,130 +0,0 @@
|
|||||||
#ifndef __hciemulator_h
|
|
||||||
#define __hciemulator_h
|
|
||||||
|
|
||||||
#include <Stream.h>
|
|
||||||
#include "SoftwareSerial.h"
|
|
||||||
|
|
||||||
#define LL_OFF 0
|
|
||||||
#define LL_ERROR 1
|
|
||||||
#define LL_WARN 2
|
|
||||||
#define LL_INFO 3
|
|
||||||
#define LL_DEBUG 4
|
|
||||||
|
|
||||||
#define DEFAULTLOGLEVEL LL_WARN
|
|
||||||
|
|
||||||
#define DEVICEID 0x02
|
|
||||||
#define BROADCASTID 0x00
|
|
||||||
#define SIMULATEKEYPRESSDELAYMS 100
|
|
||||||
|
|
||||||
|
|
||||||
// Modbus states that a baud rate higher than 19200 must use a fixed 750 us
|
|
||||||
// for inter character time out and 1.75 ms for a frame delay.
|
|
||||||
// For baud rates below 19200 the timeing is more critical and has to be calculated.
|
|
||||||
// E.g. 9600 baud in a 10 bit packet is 960 characters per second
|
|
||||||
// In milliseconds this will be 960characters per 1000ms. So for 1 character
|
|
||||||
// 1000ms/960characters is 1.04167ms per character and finaly modbus states an
|
|
||||||
// intercharacter must be 1.5T or 1.5 times longer than a normal character and thus
|
|
||||||
// 1.5T = 1.04167ms * 1.5 = 1.5625ms. A frame delay is 3.5T.
|
|
||||||
#define T1_5 750
|
|
||||||
#define T3_5 4800 //1750
|
|
||||||
|
|
||||||
|
|
||||||
enum DoorState : uint8_t {
|
|
||||||
DOOR_OPEN_POSITION = 0x20,
|
|
||||||
DOOR_CLOSE_POSITION = 0x40,
|
|
||||||
DOOR_HALF_POSITION = 0x80,
|
|
||||||
DOOR_MOVE_CLOSEPOSITION = 0x02,
|
|
||||||
DOOR_MOVE_OPENPOSITION = 0x01,
|
|
||||||
|
|
||||||
};
|
|
||||||
|
|
||||||
struct SHCIState{
|
|
||||||
bool valid;
|
|
||||||
bool lampOn;
|
|
||||||
uint8_t doorState; // see DoorState
|
|
||||||
uint8_t doorCurrentPosition;
|
|
||||||
uint8_t doorTargetPosition;
|
|
||||||
uint8_t reserved;
|
|
||||||
};
|
|
||||||
|
|
||||||
enum StateMachine: uint8_t{
|
|
||||||
WAITING,
|
|
||||||
|
|
||||||
STARTOPENDOOR,
|
|
||||||
STARTOPENDOOR_RELEASE,
|
|
||||||
|
|
||||||
STARTOPENDOORHALF,
|
|
||||||
STARTOPENDOORHALF_RELEASE,
|
|
||||||
|
|
||||||
STARTCLOSEDOOR,
|
|
||||||
STARTCLOSEDOOR_RELEASE,
|
|
||||||
|
|
||||||
STARTSTOPDOOR,
|
|
||||||
STARTSTOPDOOR_RELEASE,
|
|
||||||
|
|
||||||
STARTTOGGLELAMP,
|
|
||||||
STARTTOGGLELAMP_RELEASE,
|
|
||||||
|
|
||||||
STARTVENTPOSITION,
|
|
||||||
STARTVENTPOSITION_RELEASE
|
|
||||||
};
|
|
||||||
|
|
||||||
class HCIEmulator {
|
|
||||||
public:
|
|
||||||
typedef std::function<void(const SHCIState&)> callback_function_t;
|
|
||||||
|
|
||||||
HCIEmulator(Stream * port);
|
|
||||||
|
|
||||||
void poll();
|
|
||||||
|
|
||||||
void openDoor();
|
|
||||||
void openDoorHalf();
|
|
||||||
void closeDoor();
|
|
||||||
void stopDoor();
|
|
||||||
void toggleLamp();
|
|
||||||
void ventilationPosition();
|
|
||||||
|
|
||||||
const SHCIState& getState() {
|
|
||||||
if(micros()-m_recvTime > 2000000){
|
|
||||||
// 2 sec without statusmessage
|
|
||||||
m_state.valid = false;
|
|
||||||
}
|
|
||||||
return m_state;
|
|
||||||
};
|
|
||||||
|
|
||||||
unsigned long getMessageAge(){
|
|
||||||
return micros()-m_recvTime;
|
|
||||||
}
|
|
||||||
|
|
||||||
int getLogLevel();
|
|
||||||
void setLogLevel(int level);
|
|
||||||
|
|
||||||
void onStatusChanged(callback_function_t handler);
|
|
||||||
|
|
||||||
protected:
|
|
||||||
void processFrame();
|
|
||||||
void processDeviceStatusFrame();
|
|
||||||
void processDeviceBusScanFrame();
|
|
||||||
void processBroadcastStatusFrame();
|
|
||||||
|
|
||||||
private:
|
|
||||||
callback_function_t m_statusCallback;
|
|
||||||
Stream *m_port;
|
|
||||||
SHCIState m_state;
|
|
||||||
StateMachine m_statemachine;
|
|
||||||
|
|
||||||
unsigned long m_recvTime;
|
|
||||||
unsigned long m_lastStateTime;
|
|
||||||
unsigned long m_lastSendTime;
|
|
||||||
|
|
||||||
size_t m_rxlen;
|
|
||||||
size_t m_txlen;
|
|
||||||
|
|
||||||
unsigned char m_rxbuffer[255];
|
|
||||||
unsigned char m_txbuffer[255];
|
|
||||||
|
|
||||||
bool m_skipFrame;
|
|
||||||
};
|
|
||||||
|
|
||||||
|
|
||||||
#endif
|
|
||||||
@ -1,172 +0,0 @@
|
|||||||
#include <Arduino.h>
|
|
||||||
#include <ESPAsyncWebServer.h>
|
|
||||||
#include "AsyncJson.h"
|
|
||||||
#include "ArduinoJson.h"
|
|
||||||
#include "hciemulator.h"
|
|
||||||
#include "index_html.h"
|
|
||||||
|
|
||||||
!!! DONT USE THIS, BECAUSE OF TIMING PROBLEMS !!!
|
|
||||||
!!! USE THE ISR VERSION OR SWITCH TO ESP32 !!!
|
|
||||||
|
|
||||||
|
|
||||||
/* create this file and add your wlan credentials
|
|
||||||
const char* ssid = "MyWLANSID";
|
|
||||||
const char* password = "MYPASSWORD";
|
|
||||||
*/
|
|
||||||
#include "../../../private/credentials.h"
|
|
||||||
|
|
||||||
|
|
||||||
// switch relay sync to the lamp
|
|
||||||
// e.g. the Wifi Relay Board U4648
|
|
||||||
#define USERELAY
|
|
||||||
|
|
||||||
// use alternative uart pins
|
|
||||||
//#define SWAPUART
|
|
||||||
|
|
||||||
#define RS485 Serial
|
|
||||||
|
|
||||||
// Relay Board parameters
|
|
||||||
#define ESP8266_GPIO2 2 // Blue LED.
|
|
||||||
#define ESP8266_GPIO4 4 // Relay control.
|
|
||||||
#define ESP8266_GPIO5 5 // Optocoupler input.
|
|
||||||
#define LED_PIN ESP8266_GPIO2
|
|
||||||
|
|
||||||
|
|
||||||
// Hörmann HCP2 based on modbus rtu @57.6kB 8E1
|
|
||||||
HCIEmulator emulator(&RS485);
|
|
||||||
|
|
||||||
// webserver on port 80
|
|
||||||
AsyncWebServer server(80);
|
|
||||||
|
|
||||||
// called by ESPAsyncTCP-esphome:SyncClient.cpp (see patch) instead of delay to avoid connection breaks
|
|
||||||
void DelayHandler(void){
|
|
||||||
emulator.poll();
|
|
||||||
}
|
|
||||||
|
|
||||||
// switch GPIO4 und GPIO2 sync to the lamp
|
|
||||||
void onStatusChanged(const SHCIState& state){
|
|
||||||
//see https://ucexperiment.wordpress.com/2016/12/18/yunshan-esp8266-250v-15a-acdc-network-wifi-relay-module/
|
|
||||||
//Setting GPIO4 high, causes the relay to close the NO contact with
|
|
||||||
if(state.valid){
|
|
||||||
digitalWrite( ESP8266_GPIO4, state.lampOn );
|
|
||||||
digitalWrite(LED_PIN, state.lampOn);
|
|
||||||
}else
|
|
||||||
{
|
|
||||||
digitalWrite( ESP8266_GPIO4, false );
|
|
||||||
digitalWrite(LED_PIN, false);
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
// toggle lamp to expected state
|
|
||||||
void switchLamp(bool on){
|
|
||||||
bool toggle = (on && !emulator.getState().lampOn) || (!on && emulator.getState().lampOn);
|
|
||||||
if(toggle){
|
|
||||||
emulator.toggleLamp();
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
// setup mcu
|
|
||||||
void setup(){
|
|
||||||
|
|
||||||
//setup modbus
|
|
||||||
RS485.begin(57600,SERIAL_8E1);
|
|
||||||
#ifdef SWAPUART
|
|
||||||
RS485.swap();
|
|
||||||
#endif
|
|
||||||
|
|
||||||
|
|
||||||
//setup wifi
|
|
||||||
WiFi.mode(WIFI_STA);
|
|
||||||
WiFi.begin(ssid, password);
|
|
||||||
WiFi.setAutoReconnect(true);
|
|
||||||
while (WiFi.status() != WL_CONNECTED) {
|
|
||||||
emulator.poll();
|
|
||||||
}
|
|
||||||
|
|
||||||
// setup http server
|
|
||||||
server.on("/", HTTP_GET, [](AsyncWebServerRequest *request){
|
|
||||||
AsyncWebServerResponse *response = request->beginResponse_P( 200, "text/html", index_html,sizeof(index_html));
|
|
||||||
response->addHeader("Content-Encoding","deflate");
|
|
||||||
request->send(response);
|
|
||||||
});
|
|
||||||
|
|
||||||
server.on("/status", HTTP_GET, [](AsyncWebServerRequest *request){
|
|
||||||
const SHCIState& doorstate = emulator.getState();
|
|
||||||
AsyncResponseStream *response = request->beginResponseStream("application/json");
|
|
||||||
DynamicJsonDocument root(1024);
|
|
||||||
root["valid"] = doorstate.valid;
|
|
||||||
root["doorstate"] = doorstate.doorState;
|
|
||||||
root["doorposition"] = doorstate.doorCurrentPosition;
|
|
||||||
root["doortarget"] = doorstate.doorTargetPosition;
|
|
||||||
root["lamp"] = doorstate.lampOn;
|
|
||||||
root["debug"] = doorstate.reserved;
|
|
||||||
root["lastresponse"] = emulator.getMessageAge()/1000;
|
|
||||||
serializeJson(root,*response);
|
|
||||||
request->send(response);
|
|
||||||
});
|
|
||||||
|
|
||||||
server.on("/command", HTTP_GET, [] (AsyncWebServerRequest *request) {
|
|
||||||
if (request->hasParam("action")) {
|
|
||||||
int actionid = request->getParam("action")->value().toInt();
|
|
||||||
switch (actionid){
|
|
||||||
case 0:
|
|
||||||
emulator.closeDoor();
|
|
||||||
break;
|
|
||||||
case 1:
|
|
||||||
emulator.openDoor();
|
|
||||||
break;
|
|
||||||
case 2:
|
|
||||||
emulator.stopDoor();
|
|
||||||
break;
|
|
||||||
case 3:
|
|
||||||
emulator.ventilationPosition();
|
|
||||||
break;
|
|
||||||
case 4:
|
|
||||||
emulator.openDoorHalf();
|
|
||||||
break;
|
|
||||||
case 5:
|
|
||||||
emulator.toggleLamp();
|
|
||||||
break;
|
|
||||||
default:
|
|
||||||
break;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
request->send(200, "text/plain", "OK");
|
|
||||||
});
|
|
||||||
|
|
||||||
server.on("/update", HTTP_GET, [] (AsyncWebServerRequest *request) {
|
|
||||||
if (request->hasParam("channel") && request->hasParam("state")) {
|
|
||||||
String channel = request->getParam("channel")->value();
|
|
||||||
String state = request->getParam("state")->value();
|
|
||||||
if(channel.equals("door")){
|
|
||||||
if(state=="1"){
|
|
||||||
emulator.openDoor();
|
|
||||||
}else{
|
|
||||||
emulator.closeDoor();
|
|
||||||
}
|
|
||||||
}
|
|
||||||
if(channel.equals("light")){
|
|
||||||
switchLamp(state=="1");
|
|
||||||
}
|
|
||||||
}
|
|
||||||
request->send(200, "text/plain", "OK");
|
|
||||||
});
|
|
||||||
|
|
||||||
server.begin();
|
|
||||||
|
|
||||||
//setup relay board
|
|
||||||
#ifdef USERELAY
|
|
||||||
pinMode( ESP8266_GPIO4, OUTPUT ); // Relay control pin.
|
|
||||||
pinMode( ESP8266_GPIO5, INPUT_PULLUP ); // Input pin.
|
|
||||||
pinMode( LED_PIN, OUTPUT ); // ESP8266 module blue L
|
|
||||||
digitalWrite( ESP8266_GPIO4, 0 );
|
|
||||||
digitalWrite(LED_PIN,0);
|
|
||||||
emulator.onStatusChanged(onStatusChanged);
|
|
||||||
#endif
|
|
||||||
|
|
||||||
}
|
|
||||||
|
|
||||||
// mainloop
|
|
||||||
void loop(){
|
|
||||||
emulator.poll();
|
|
||||||
}
|
|
||||||
@ -1,11 +0,0 @@
|
|||||||
|
|
||||||
This directory is intended for PlatformIO Unit Testing and project tests.
|
|
||||||
|
|
||||||
Unit Testing is a software testing method by which individual units of
|
|
||||||
source code, sets of one or more MCU program modules together with associated
|
|
||||||
control data, usage procedures, and operating procedures, are tested to
|
|
||||||
determine whether they are fit for use. Unit testing finds problems early
|
|
||||||
in the development cycle.
|
|
||||||
|
|
||||||
More information about PlatformIO Unit Testing:
|
|
||||||
- https://docs.platformio.org/page/plus/unit-testing.html
|
|
||||||
File diff suppressed because one or more lines are too long
@ -5,7 +5,7 @@
|
|||||||
#include <AsyncJson.h>
|
#include <AsyncJson.h>
|
||||||
#include <ArduinoJson.h>
|
#include <ArduinoJson.h>
|
||||||
#include <Wire.h>
|
#include <Wire.h>
|
||||||
#include "index_html.h"
|
#include "../../../WebUI/index_html.h"
|
||||||
#include "../../Arduino/src/i2cshare.h"
|
#include "../../Arduino/src/i2cshare.h"
|
||||||
|
|
||||||
|
|
||||||
|
|||||||
@ -1 +0,0 @@
|
|||||||
python compress.py
|
|
||||||
@ -1,35 +0,0 @@
|
|||||||
#pip install htmlmin
|
|
||||||
#or python -m pip install htmlmin
|
|
||||||
#pip install jsmin
|
|
||||||
#or python -m pip install jsmin
|
|
||||||
|
|
||||||
import gzip
|
|
||||||
import zlib
|
|
||||||
import htmlmin
|
|
||||||
from jsmin import jsmin
|
|
||||||
|
|
||||||
|
|
||||||
|
|
||||||
content = ""
|
|
||||||
with open('index.html','rt',encoding="utf-8") as f:
|
|
||||||
content=f.read()
|
|
||||||
|
|
||||||
|
|
||||||
content = htmlmin.minify(content, remove_comments=True, remove_empty_space=True, remove_all_empty_space=True, reduce_empty_attributes=True, reduce_boolean_attributes=False, remove_optional_attribute_quotes=True, convert_charrefs=True, keep_pre=False)
|
|
||||||
|
|
||||||
|
|
||||||
import re
|
|
||||||
regex = r"<script>(.+?)<\/script>"
|
|
||||||
content = re.sub(regex, lambda x: "<script>"+jsmin(x.group(1))+"</script>" ,content, 0, re.DOTALL)
|
|
||||||
|
|
||||||
result =""
|
|
||||||
for c in zlib.compress(content.encode("UTF-8"),9):
|
|
||||||
result= result + ("0x%02X" %c)
|
|
||||||
if len(result)> 0:
|
|
||||||
result=result + ","
|
|
||||||
|
|
||||||
|
|
||||||
with open('../index_html.h',"wt") as f:
|
|
||||||
f.write("const uint8_t index_html[] PROGMEM = {");
|
|
||||||
f.write(result.strip(","))
|
|
||||||
f.write("};");
|
|
||||||
@ -1,159 +0,0 @@
|
|||||||
<!DOCTYPE HTML><html>
|
|
||||||
<head>
|
|
||||||
<title>Garagentor Steuerung</title>
|
|
||||||
<meta name="viewport" content="width=device-width, initial-scale=1">
|
|
||||||
<meta charset="UTF-8">
|
|
||||||
<link rel="icon" href="data:,">
|
|
||||||
<style>
|
|
||||||
html {font-family: Arial; display: inline-block; text-align: center;}
|
|
||||||
h2 {font-size: 3.0rem;}
|
|
||||||
p {font-size: 3.0rem;}
|
|
||||||
body {max-width: 600px; margin:0px auto; padding-bottom: 25px;}
|
|
||||||
.switch {position: relative; display: inline-block; width: 80px; height: 48px}
|
|
||||||
.switch input {display: none}
|
|
||||||
.slider {position: absolute; top: 0; left: 0; right: 0; bottom: 0; background-color: #ccc; border-radius: 6px}
|
|
||||||
.slider:before {position: absolute; content: ""; height: 32px; width: 32px; left: 8px; bottom: 8px; background-color: #fff; -webkit-transition: .4s; transition: .4s; border-radius: 3px}
|
|
||||||
input:checked+.slider {background-color: #b30000}
|
|
||||||
input:checked+.slider:before {-webkit-transform: translateX(32px); -ms-transform: translateX(32px); transform: translateX(32px)}
|
|
||||||
|
|
||||||
.button {
|
|
||||||
border: 4px;
|
|
||||||
border-style: solid;
|
|
||||||
color: black;
|
|
||||||
width: 100px;
|
|
||||||
height: 100px;
|
|
||||||
text-align: center;
|
|
||||||
display: inline;
|
|
||||||
text-decoration: none;
|
|
||||||
display: inline-block;
|
|
||||||
font-weight: bold;
|
|
||||||
font-size: 20px;
|
|
||||||
margin: 4px 2px;
|
|
||||||
cursor: pointer;
|
|
||||||
border-radius: 50px;
|
|
||||||
}
|
|
||||||
.buttonred {border-color: #ED5961;}
|
|
||||||
.buttonyellow {border-color: #fcca00;}
|
|
||||||
.buttongreen {border-color: #48bd81;}
|
|
||||||
</style>
|
|
||||||
</head>
|
|
||||||
<body>
|
|
||||||
<h2>Garagentor</h2>
|
|
||||||
<canvas width="250px" height="250px" id="dc"></canvas>
|
|
||||||
<h3 id="status">warte auf Verbindung.</h3>
|
|
||||||
|
|
||||||
<hr/>
|
|
||||||
<button class="button buttonred" onclick="doCommand(1)">Auf</button> <button class="button buttonyellow" onclick="doCommand(2)">Stop</button> <button class="button buttongreen" onclick="doCommand(0)">Zu</button>
|
|
||||||
<hr/>
|
|
||||||
<h4>Licht</h4><label class="switch"><input type="checkbox" onchange="doCommand(5)" id="light"><span class="slider"></span></label>
|
|
||||||
<hr/>
|
|
||||||
|
|
||||||
<script>
|
|
||||||
|
|
||||||
|
|
||||||
doorpos = 10;
|
|
||||||
dir = -1;
|
|
||||||
isconnected = false;
|
|
||||||
var animation;
|
|
||||||
function startDoorAnimation() {
|
|
||||||
if(!animation){
|
|
||||||
animation = setInterval(Draw, 200);
|
|
||||||
}
|
|
||||||
|
|
||||||
}
|
|
||||||
function stopDoorAnimation() {
|
|
||||||
if(animation){
|
|
||||||
clearInterval(animation);
|
|
||||||
}
|
|
||||||
animation = null;
|
|
||||||
}
|
|
||||||
|
|
||||||
function Draw(){
|
|
||||||
var svg =document.getElementById("svg");
|
|
||||||
var dc = document.getElementById("dc");
|
|
||||||
var ctx = dc.getContext("2d");
|
|
||||||
width = dc.width;
|
|
||||||
height = dc.height;
|
|
||||||
ctx.clearRect(0, 0, width, height);
|
|
||||||
xa= [18,18,10,3,174,347,340,332,332,297,297,52,52,18];
|
|
||||||
ya= [327,114,117,100,22,100,117,114,327,327,112,112,327,327];
|
|
||||||
|
|
||||||
ctx.fillStyle = "black";
|
|
||||||
ctx.beginPath();
|
|
||||||
for (i =0;i<xa.length;i++){
|
|
||||||
if(i==0){
|
|
||||||
ctx.moveTo((xa[i]/350) * width , (ya[i]/350)*width);
|
|
||||||
}else{
|
|
||||||
ctx.lineTo((xa[i]/350) * width, (ya[i]/350)*width);
|
|
||||||
}
|
|
||||||
}
|
|
||||||
ctx.fill();
|
|
||||||
|
|
||||||
for(i=0;i<doorpos;i++){
|
|
||||||
ctx.fillRect((62/350) * width, ((120+21*i)/350) * width, (225/350) * width, (18/350) * width);
|
|
||||||
}
|
|
||||||
doorpos+=dir;
|
|
||||||
|
|
||||||
if(dir<0 && doorpos<=0){
|
|
||||||
dir=dir*-1;
|
|
||||||
}
|
|
||||||
if(dir>0 &&doorpos>=10){
|
|
||||||
dir=dir*-1;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
function doCommand(action) {
|
|
||||||
if(!isconnected){return;}
|
|
||||||
var xhr = new XMLHttpRequest();
|
|
||||||
xhr.open("GET", "/command?action="+action, true);
|
|
||||||
xhr.send();
|
|
||||||
}
|
|
||||||
|
|
||||||
function setDoorState(state){
|
|
||||||
stopDoorAnimation();
|
|
||||||
if(state == 0) {doorpos = 10;dir = -1};
|
|
||||||
if(state == 1) {doorpos = 0; dir = 1};
|
|
||||||
if(state == 2) {doorpos = 5; dir = 1};
|
|
||||||
Draw();
|
|
||||||
if(state == 3) startDoorAnimation();
|
|
||||||
}
|
|
||||||
|
|
||||||
function getStatusText(id){
|
|
||||||
result = "Das Tor "
|
|
||||||
switch(id)
|
|
||||||
{
|
|
||||||
case 0x20: setDoorState(1); return result+"ist geöffnet.";
|
|
||||||
case 0x40: setDoorState(0); return result+"ist geschlossen.";
|
|
||||||
case 0x80: setDoorState(2); return result+"ist teilgeöffnet.";
|
|
||||||
case 0x00: setDoorState(2); return result+"ist teilgeöffnet.";
|
|
||||||
case 0x02: setDoorState(3); return result+"schließt.";
|
|
||||||
case 0x01: setDoorState(3); return result+"öffnet.";
|
|
||||||
case -1: setDoorState(0); return "keine Verbindung zum Tor.";
|
|
||||||
default: return "unbekanter Status: " + id;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
function updateData(){
|
|
||||||
var xmlhttp = new XMLHttpRequest();
|
|
||||||
xmlhttp.onreadystatechange = function() {
|
|
||||||
if (this.readyState == 4 && this.status == 200) {
|
|
||||||
var status = JSON.parse(this.responseText);
|
|
||||||
isconnected = status.valid;
|
|
||||||
document.getElementById("status").innerHTML = getStatusText(status.valid?status.doorstate:-1);
|
|
||||||
document.getElementById("light").checked = status.lamp & status.valid;
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
isconnected= false;
|
|
||||||
};
|
|
||||||
xmlhttp.open("GET", "/status", true);
|
|
||||||
xmlhttp.send();
|
|
||||||
}
|
|
||||||
|
|
||||||
Draw();
|
|
||||||
updateData();
|
|
||||||
setInterval(updateData, 3000);
|
|
||||||
|
|
||||||
|
|
||||||
</script>
|
|
||||||
</body>
|
|
||||||
</html>
|
|
||||||
@ -1 +0,0 @@
|
|||||||
python -m http.server
|
|
||||||
@ -1,9 +0,0 @@
|
|||||||
{
|
|
||||||
"valid" : true,
|
|
||||||
"doorstate" : 1,
|
|
||||||
"doorposition" : 0,
|
|
||||||
"doortarget" : 0,
|
|
||||||
"lamp" : true,
|
|
||||||
"debug" : 0,
|
|
||||||
"lastresponse" : 0
|
|
||||||
}
|
|
||||||
File diff suppressed because one or more lines are too long
@ -5,6 +5,7 @@
|
|||||||
#include "ArduinoJson.h"
|
#include "ArduinoJson.h"
|
||||||
#include "hciemulator.h"
|
#include "hciemulator.h"
|
||||||
#include "index_html.h"
|
#include "index_html.h"
|
||||||
|
#include "../../WebUI/index_html.h"
|
||||||
|
|
||||||
/* create this file and add your wlan credentials
|
/* create this file and add your wlan credentials
|
||||||
const char* ssid = "MyWLANSID";
|
const char* ssid = "MyWLANSID";
|
||||||
|
|||||||
@ -1 +0,0 @@
|
|||||||
python compress.py
|
|
||||||
@ -1,35 +0,0 @@
|
|||||||
#pip install htmlmin
|
|
||||||
#or python -m pip install htmlmin
|
|
||||||
#pip install jsmin
|
|
||||||
#or python -m pip install jsmin
|
|
||||||
|
|
||||||
import gzip
|
|
||||||
import zlib
|
|
||||||
import htmlmin
|
|
||||||
from jsmin import jsmin
|
|
||||||
|
|
||||||
|
|
||||||
|
|
||||||
content = ""
|
|
||||||
with open('index.html','rt',encoding="utf-8") as f:
|
|
||||||
content=f.read()
|
|
||||||
|
|
||||||
|
|
||||||
content = htmlmin.minify(content, remove_comments=True, remove_empty_space=True, remove_all_empty_space=True, reduce_empty_attributes=True, reduce_boolean_attributes=False, remove_optional_attribute_quotes=True, convert_charrefs=True, keep_pre=False)
|
|
||||||
|
|
||||||
|
|
||||||
import re
|
|
||||||
regex = r"<script>(.+?)<\/script>"
|
|
||||||
content = re.sub(regex, lambda x: "<script>"+jsmin(x.group(1))+"</script>" ,content, 0, re.DOTALL)
|
|
||||||
|
|
||||||
result =""
|
|
||||||
for c in zlib.compress(content.encode("UTF-8"),9):
|
|
||||||
result= result + ("0x%02X" %c)
|
|
||||||
if len(result)> 0:
|
|
||||||
result=result + ","
|
|
||||||
|
|
||||||
|
|
||||||
with open('../index_html.h',"wt") as f:
|
|
||||||
f.write("const uint8_t index_html[] PROGMEM = {");
|
|
||||||
f.write(result.strip(","))
|
|
||||||
f.write("};");
|
|
||||||
@ -1,159 +0,0 @@
|
|||||||
<!DOCTYPE HTML><html>
|
|
||||||
<head>
|
|
||||||
<title>Garagentor Steuerung</title>
|
|
||||||
<meta name="viewport" content="width=device-width, initial-scale=1">
|
|
||||||
<meta charset="UTF-8">
|
|
||||||
<link rel="icon" href="data:,">
|
|
||||||
<style>
|
|
||||||
html {font-family: Arial; display: inline-block; text-align: center;}
|
|
||||||
h2 {font-size: 3.0rem;}
|
|
||||||
p {font-size: 3.0rem;}
|
|
||||||
body {max-width: 600px; margin:0px auto; padding-bottom: 25px;}
|
|
||||||
.switch {position: relative; display: inline-block; width: 80px; height: 48px}
|
|
||||||
.switch input {display: none}
|
|
||||||
.slider {position: absolute; top: 0; left: 0; right: 0; bottom: 0; background-color: #ccc; border-radius: 6px}
|
|
||||||
.slider:before {position: absolute; content: ""; height: 32px; width: 32px; left: 8px; bottom: 8px; background-color: #fff; -webkit-transition: .4s; transition: .4s; border-radius: 3px}
|
|
||||||
input:checked+.slider {background-color: #b30000}
|
|
||||||
input:checked+.slider:before {-webkit-transform: translateX(32px); -ms-transform: translateX(32px); transform: translateX(32px)}
|
|
||||||
|
|
||||||
.button {
|
|
||||||
border: 4px;
|
|
||||||
border-style: solid;
|
|
||||||
color: black;
|
|
||||||
width: 100px;
|
|
||||||
height: 100px;
|
|
||||||
text-align: center;
|
|
||||||
display: inline;
|
|
||||||
text-decoration: none;
|
|
||||||
display: inline-block;
|
|
||||||
font-weight: bold;
|
|
||||||
font-size: 20px;
|
|
||||||
margin: 4px 2px;
|
|
||||||
cursor: pointer;
|
|
||||||
border-radius: 50px;
|
|
||||||
}
|
|
||||||
.buttonred {border-color: #ED5961;}
|
|
||||||
.buttonyellow {border-color: #fcca00;}
|
|
||||||
.buttongreen {border-color: #48bd81;}
|
|
||||||
</style>
|
|
||||||
</head>
|
|
||||||
<body>
|
|
||||||
<h2>Garagentor</h2>
|
|
||||||
<canvas width="250px" height="250px" id="dc"></canvas>
|
|
||||||
<h3 id="status">warte auf Verbindung.</h3>
|
|
||||||
|
|
||||||
<hr/>
|
|
||||||
<button class="button buttonred" onclick="doCommand(1)">Auf</button> <button class="button buttonyellow" onclick="doCommand(2)">Stop</button> <button class="button buttongreen" onclick="doCommand(0)">Zu</button>
|
|
||||||
<hr/>
|
|
||||||
<h4>Licht</h4><label class="switch"><input type="checkbox" onchange="doCommand(5)" id="light"><span class="slider"></span></label>
|
|
||||||
<hr/>
|
|
||||||
|
|
||||||
<script>
|
|
||||||
|
|
||||||
|
|
||||||
doorpos = 10;
|
|
||||||
dir = -1;
|
|
||||||
isconnected = false;
|
|
||||||
var animation;
|
|
||||||
function startDoorAnimation() {
|
|
||||||
if(!animation){
|
|
||||||
animation = setInterval(Draw, 200);
|
|
||||||
}
|
|
||||||
|
|
||||||
}
|
|
||||||
function stopDoorAnimation() {
|
|
||||||
if(animation){
|
|
||||||
clearInterval(animation);
|
|
||||||
}
|
|
||||||
animation = null;
|
|
||||||
}
|
|
||||||
|
|
||||||
function Draw(){
|
|
||||||
var svg =document.getElementById("svg");
|
|
||||||
var dc = document.getElementById("dc");
|
|
||||||
var ctx = dc.getContext("2d");
|
|
||||||
width = dc.width;
|
|
||||||
height = dc.height;
|
|
||||||
ctx.clearRect(0, 0, width, height);
|
|
||||||
xa= [18,18,10,3,174,347,340,332,332,297,297,52,52,18];
|
|
||||||
ya= [327,114,117,100,22,100,117,114,327,327,112,112,327,327];
|
|
||||||
|
|
||||||
ctx.fillStyle = "black";
|
|
||||||
ctx.beginPath();
|
|
||||||
for (i =0;i<xa.length;i++){
|
|
||||||
if(i==0){
|
|
||||||
ctx.moveTo((xa[i]/350) * width , (ya[i]/350)*width);
|
|
||||||
}else{
|
|
||||||
ctx.lineTo((xa[i]/350) * width, (ya[i]/350)*width);
|
|
||||||
}
|
|
||||||
}
|
|
||||||
ctx.fill();
|
|
||||||
|
|
||||||
for(i=0;i<doorpos;i++){
|
|
||||||
ctx.fillRect((62/350) * width, ((120+21*i)/350) * width, (225/350) * width, (18/350) * width);
|
|
||||||
}
|
|
||||||
doorpos+=dir;
|
|
||||||
|
|
||||||
if(dir<0 && doorpos<=0){
|
|
||||||
dir=dir*-1;
|
|
||||||
}
|
|
||||||
if(dir>0 &&doorpos>=10){
|
|
||||||
dir=dir*-1;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
function doCommand(action) {
|
|
||||||
if(!isconnected){return;}
|
|
||||||
var xhr = new XMLHttpRequest();
|
|
||||||
xhr.open("GET", "/command?action="+action, true);
|
|
||||||
xhr.send();
|
|
||||||
}
|
|
||||||
|
|
||||||
function setDoorState(state){
|
|
||||||
stopDoorAnimation();
|
|
||||||
if(state == 0) {doorpos = 10;dir = -1};
|
|
||||||
if(state == 1) {doorpos = 0; dir = 1};
|
|
||||||
if(state == 2) {doorpos = 5; dir = 1};
|
|
||||||
Draw();
|
|
||||||
if(state == 3) startDoorAnimation();
|
|
||||||
}
|
|
||||||
|
|
||||||
function getStatusText(id){
|
|
||||||
result = "Das Tor "
|
|
||||||
switch(id)
|
|
||||||
{
|
|
||||||
case 0x20: setDoorState(1); return result+"ist geöffnet.";
|
|
||||||
case 0x40: setDoorState(0); return result+"ist geschlossen.";
|
|
||||||
case 0x80: setDoorState(2); return result+"ist teilgeöffnet.";
|
|
||||||
case 0x00: setDoorState(2); return result+"ist teilgeöffnet.";
|
|
||||||
case 0x02: setDoorState(3); return result+"schließt.";
|
|
||||||
case 0x01: setDoorState(3); return result+"öffnet.";
|
|
||||||
case -1: setDoorState(0); return "keine Verbindung zum Tor.";
|
|
||||||
default: return "unbekanter Status: " + id;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
function updateData(){
|
|
||||||
var xmlhttp = new XMLHttpRequest();
|
|
||||||
xmlhttp.onreadystatechange = function() {
|
|
||||||
if (this.readyState == 4 && this.status == 200) {
|
|
||||||
var status = JSON.parse(this.responseText);
|
|
||||||
isconnected = status.valid;
|
|
||||||
document.getElementById("status").innerHTML = getStatusText(status.valid?status.doorstate:-1);
|
|
||||||
document.getElementById("light").checked = status.lamp & status.valid;
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
isconnected= false;
|
|
||||||
};
|
|
||||||
xmlhttp.open("GET", "/status", true);
|
|
||||||
xmlhttp.send();
|
|
||||||
}
|
|
||||||
|
|
||||||
Draw();
|
|
||||||
updateData();
|
|
||||||
setInterval(updateData, 3000);
|
|
||||||
|
|
||||||
|
|
||||||
</script>
|
|
||||||
</body>
|
|
||||||
</html>
|
|
||||||
@ -1 +0,0 @@
|
|||||||
python -m http.server
|
|
||||||
@ -1,9 +0,0 @@
|
|||||||
{
|
|
||||||
"valid" : true,
|
|
||||||
"doorstate" : 1,
|
|
||||||
"doorposition" : 0,
|
|
||||||
"doortarget" : 0,
|
|
||||||
"lamp" : true,
|
|
||||||
"debug" : 0,
|
|
||||||
"lastresponse" : 0
|
|
||||||
}
|
|
||||||
File diff suppressed because one or more lines are too long
@ -5,7 +5,7 @@
|
|||||||
#include <AsyncJson.h>
|
#include <AsyncJson.h>
|
||||||
#include <ArduinoJson.h>
|
#include <ArduinoJson.h>
|
||||||
#include "hciemulator.h"
|
#include "hciemulator.h"
|
||||||
#include "index_html.h"
|
#include "../../WebUI/index_html.h"
|
||||||
|
|
||||||
|
|
||||||
/* create this file and add your wlan credentials
|
/* create this file and add your wlan credentials
|
||||||
|
|||||||
@ -1 +0,0 @@
|
|||||||
python compress.py
|
|
||||||
@ -1,35 +0,0 @@
|
|||||||
#pip install htmlmin
|
|
||||||
#or python -m pip install htmlmin
|
|
||||||
#pip install jsmin
|
|
||||||
#or python -m pip install jsmin
|
|
||||||
|
|
||||||
import gzip
|
|
||||||
import zlib
|
|
||||||
import htmlmin
|
|
||||||
from jsmin import jsmin
|
|
||||||
|
|
||||||
|
|
||||||
|
|
||||||
content = ""
|
|
||||||
with open('index.html','rt',encoding="utf-8") as f:
|
|
||||||
content=f.read()
|
|
||||||
|
|
||||||
|
|
||||||
content = htmlmin.minify(content, remove_comments=True, remove_empty_space=True, remove_all_empty_space=True, reduce_empty_attributes=True, reduce_boolean_attributes=False, remove_optional_attribute_quotes=True, convert_charrefs=True, keep_pre=False)
|
|
||||||
|
|
||||||
|
|
||||||
import re
|
|
||||||
regex = r"<script>(.+?)<\/script>"
|
|
||||||
content = re.sub(regex, lambda x: "<script>"+jsmin(x.group(1))+"</script>" ,content, 0, re.DOTALL)
|
|
||||||
|
|
||||||
result =""
|
|
||||||
for c in zlib.compress(content.encode("UTF-8"),9):
|
|
||||||
result= result + ("0x%02X" %c)
|
|
||||||
if len(result)> 0:
|
|
||||||
result=result + ","
|
|
||||||
|
|
||||||
|
|
||||||
with open('../index_html.h',"wt") as f:
|
|
||||||
f.write("const uint8_t index_html[] PROGMEM = {");
|
|
||||||
f.write(result.strip(","))
|
|
||||||
f.write("};");
|
|
||||||
@ -1,159 +0,0 @@
|
|||||||
<!DOCTYPE HTML><html>
|
|
||||||
<head>
|
|
||||||
<title>Garagentor Steuerung</title>
|
|
||||||
<meta name="viewport" content="width=device-width, initial-scale=1">
|
|
||||||
<meta charset="UTF-8">
|
|
||||||
<link rel="icon" href="data:,">
|
|
||||||
<style>
|
|
||||||
html {font-family: Arial; display: inline-block; text-align: center;}
|
|
||||||
h2 {font-size: 3.0rem;}
|
|
||||||
p {font-size: 3.0rem;}
|
|
||||||
body {max-width: 600px; margin:0px auto; padding-bottom: 25px;}
|
|
||||||
.switch {position: relative; display: inline-block; width: 80px; height: 48px}
|
|
||||||
.switch input {display: none}
|
|
||||||
.slider {position: absolute; top: 0; left: 0; right: 0; bottom: 0; background-color: #ccc; border-radius: 6px}
|
|
||||||
.slider:before {position: absolute; content: ""; height: 32px; width: 32px; left: 8px; bottom: 8px; background-color: #fff; -webkit-transition: .4s; transition: .4s; border-radius: 3px}
|
|
||||||
input:checked+.slider {background-color: #b30000}
|
|
||||||
input:checked+.slider:before {-webkit-transform: translateX(32px); -ms-transform: translateX(32px); transform: translateX(32px)}
|
|
||||||
|
|
||||||
.button {
|
|
||||||
border: 4px;
|
|
||||||
border-style: solid;
|
|
||||||
color: black;
|
|
||||||
width: 100px;
|
|
||||||
height: 100px;
|
|
||||||
text-align: center;
|
|
||||||
display: inline;
|
|
||||||
text-decoration: none;
|
|
||||||
display: inline-block;
|
|
||||||
font-weight: bold;
|
|
||||||
font-size: 20px;
|
|
||||||
margin: 4px 2px;
|
|
||||||
cursor: pointer;
|
|
||||||
border-radius: 50px;
|
|
||||||
}
|
|
||||||
.buttonred {border-color: #ED5961;}
|
|
||||||
.buttonyellow {border-color: #fcca00;}
|
|
||||||
.buttongreen {border-color: #48bd81;}
|
|
||||||
</style>
|
|
||||||
</head>
|
|
||||||
<body>
|
|
||||||
<h2>Garagentor</h2>
|
|
||||||
<canvas width="250px" height="250px" id="dc"></canvas>
|
|
||||||
<h3 id="status">warte auf Verbindung.</h3>
|
|
||||||
|
|
||||||
<hr/>
|
|
||||||
<button class="button buttonred" onclick="doCommand(1)">Auf</button> <button class="button buttonyellow" onclick="doCommand(2)">Stop</button> <button class="button buttongreen" onclick="doCommand(0)">Zu</button>
|
|
||||||
<hr/>
|
|
||||||
<h4>Licht</h4><label class="switch"><input type="checkbox" onchange="doCommand(5)" id="light"><span class="slider"></span></label>
|
|
||||||
<hr/>
|
|
||||||
|
|
||||||
<script>
|
|
||||||
|
|
||||||
|
|
||||||
doorpos = 10;
|
|
||||||
dir = -1;
|
|
||||||
isconnected = false;
|
|
||||||
var animation;
|
|
||||||
function startDoorAnimation() {
|
|
||||||
if(!animation){
|
|
||||||
animation = setInterval(Draw, 200);
|
|
||||||
}
|
|
||||||
|
|
||||||
}
|
|
||||||
function stopDoorAnimation() {
|
|
||||||
if(animation){
|
|
||||||
clearInterval(animation);
|
|
||||||
}
|
|
||||||
animation = null;
|
|
||||||
}
|
|
||||||
|
|
||||||
function Draw(){
|
|
||||||
var svg =document.getElementById("svg");
|
|
||||||
var dc = document.getElementById("dc");
|
|
||||||
var ctx = dc.getContext("2d");
|
|
||||||
width = dc.width;
|
|
||||||
height = dc.height;
|
|
||||||
ctx.clearRect(0, 0, width, height);
|
|
||||||
xa= [18,18,10,3,174,347,340,332,332,297,297,52,52,18];
|
|
||||||
ya= [327,114,117,100,22,100,117,114,327,327,112,112,327,327];
|
|
||||||
|
|
||||||
ctx.fillStyle = "black";
|
|
||||||
ctx.beginPath();
|
|
||||||
for (i =0;i<xa.length;i++){
|
|
||||||
if(i==0){
|
|
||||||
ctx.moveTo((xa[i]/350) * width , (ya[i]/350)*width);
|
|
||||||
}else{
|
|
||||||
ctx.lineTo((xa[i]/350) * width, (ya[i]/350)*width);
|
|
||||||
}
|
|
||||||
}
|
|
||||||
ctx.fill();
|
|
||||||
|
|
||||||
for(i=0;i<doorpos;i++){
|
|
||||||
ctx.fillRect((62/350) * width, ((120+21*i)/350) * width, (225/350) * width, (18/350) * width);
|
|
||||||
}
|
|
||||||
doorpos+=dir;
|
|
||||||
|
|
||||||
if(dir<0 && doorpos<=0){
|
|
||||||
dir=dir*-1;
|
|
||||||
}
|
|
||||||
if(dir>0 &&doorpos>=10){
|
|
||||||
dir=dir*-1;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
function doCommand(action) {
|
|
||||||
if(!isconnected){return;}
|
|
||||||
var xhr = new XMLHttpRequest();
|
|
||||||
xhr.open("GET", "/command?action="+action, true);
|
|
||||||
xhr.send();
|
|
||||||
}
|
|
||||||
|
|
||||||
function setDoorState(state){
|
|
||||||
stopDoorAnimation();
|
|
||||||
if(state == 0) {doorpos = 10;dir = -1};
|
|
||||||
if(state == 1) {doorpos = 0; dir = 1};
|
|
||||||
if(state == 2) {doorpos = 5; dir = 1};
|
|
||||||
Draw();
|
|
||||||
if(state == 3) startDoorAnimation();
|
|
||||||
}
|
|
||||||
|
|
||||||
function getStatusText(id){
|
|
||||||
result = "Das Tor "
|
|
||||||
switch(id)
|
|
||||||
{
|
|
||||||
case 0x20: setDoorState(1); return result+"ist geöffnet.";
|
|
||||||
case 0x40: setDoorState(0); return result+"ist geschlossen.";
|
|
||||||
case 0x80: setDoorState(2); return result+"ist teilgeöffnet.";
|
|
||||||
case 0x00: setDoorState(2); return result+"ist teilgeöffnet.";
|
|
||||||
case 0x02: setDoorState(3); return result+"schließt.";
|
|
||||||
case 0x01: setDoorState(3); return result+"öffnet.";
|
|
||||||
case -1: setDoorState(0); return "keine Verbindung zum Tor.";
|
|
||||||
default: return "unbekanter Status: " + id;
|
|
||||||
}
|
|
||||||
}
|
|
||||||
|
|
||||||
function updateData(){
|
|
||||||
var xmlhttp = new XMLHttpRequest();
|
|
||||||
xmlhttp.onreadystatechange = function() {
|
|
||||||
if (this.readyState == 4 && this.status == 200) {
|
|
||||||
var status = JSON.parse(this.responseText);
|
|
||||||
isconnected = status.valid;
|
|
||||||
document.getElementById("status").innerHTML = getStatusText(status.valid?status.doorstate:-1);
|
|
||||||
document.getElementById("light").checked = status.lamp & status.valid;
|
|
||||||
return;
|
|
||||||
}
|
|
||||||
isconnected= false;
|
|
||||||
};
|
|
||||||
xmlhttp.open("GET", "/status", true);
|
|
||||||
xmlhttp.send();
|
|
||||||
}
|
|
||||||
|
|
||||||
Draw();
|
|
||||||
updateData();
|
|
||||||
setInterval(updateData, 3000);
|
|
||||||
|
|
||||||
|
|
||||||
</script>
|
|
||||||
</body>
|
|
||||||
</html>
|
|
||||||
@ -1 +0,0 @@
|
|||||||
python -m http.server
|
|
||||||
@ -1,9 +0,0 @@
|
|||||||
{
|
|
||||||
"valid" : true,
|
|
||||||
"doorstate" : 1,
|
|
||||||
"doorposition" : 0,
|
|
||||||
"doortarget" : 0,
|
|
||||||
"lamp" : true,
|
|
||||||
"debug" : 0,
|
|
||||||
"lastresponse" : 0
|
|
||||||
}
|
|
||||||
BIN
WebUI/webpage/favicon.png
Normal file
BIN
WebUI/webpage/favicon.png
Normal file
Binary file not shown.
|
After Width: | Height: | Size: 8.1 KiB |
Loading…
Reference in New Issue
Block a user
